Engine

 PU086T(205ps/2200rpm) DOOSAN

 Engine rpm

 1900 RPM

 Maximum output

 64 m³/h(high), 100 m³/h(low)

Main cylinder

 Ø130/Ø80x1400ST

 Concrete cylinder

 Ø230X1400ST

Cycling system

 Hydraulic with manual overrides

       Stroke per minute

 18(high), 30(low)

 Concrete pressure

 111 bar(high), 69 bar(low)

 Hopper capacity

 0.6m³

 S-tube

 Ø200XØ150

 Hydraulic pump

 KCP - K3V180S

 Max. aggregate size

 40 mm

 Vertical distance

 145 M (slump 8cm)

 Horizontal distance

 245 M (slump 8cm)
